HP 16700A - Page 58

J7
J8
100-pin
cable
80-pin
cable
J5
J6
J4
When ordered by itself, the card is cabled as a single module. Directions for
connecting the cables are also printed on the circuit board.
57
16550p02
for HP 16600A Series/ HP 16700A/ HP 16702A
HP 16550AHP 16550A
HP 16550AHP 16550A
Single-Card Module
