Item Component Spare part
number
(1) Display assembly [43.9-cm 17.3-in]
NOTE: Displays are only spared at the subcomponent level.
NOTE: For display assembly spare part information, see Display assembly subcomponents on page 21.
(2) Top cover/keyboard (ash silver) (includes TouchPad)
NOTE: For a detailed list of keyboard country codes, see Top cover/keyboard on page 79.
For use in models without a backlight:
●
Black 856698-xx1
●
Turbo silver 856699-xx1
●
White silver 856700-xx1
●
Red 856757-xx1
●
Teal 856758-xx1
●
Blue 856759-xx1
For use in models with a backlight:
●
Black 856771-xx1
●
Turbo silver 856772-xx1
●
White silver 856773-xx1
●
Red 856775-xx1
●
Teal 856776-xx1
●
Blue 856777-xx1
(3) USB board 856613-001
(4) Power connector cable 856680-001
(5) Power button board 856612-001
(6) TouchPad board 858259-001
Heat sink assembly (includes replacement thermal materials):
(7) For use in models with Intel Pentium or Celeron processors and UMA graphics 858503-001
(8) For use in models with Intel Core processors and UMA graphics 856681-001
(9) For use in models with Intel Core processors and discrete graphics 856682-001
(10) For use in models with discrete graphics 858504-001
(11) Solid-state drive board 856614-001
(12) Solid-state drive
256 GB 865902-003
128 GB 827560-025
(13) Solid-state drive holder 858260-001
(14) Hard drive (does not include bracket)
18 Chapter 3 Illustrated parts catalog
