Item Component Spare part
number
●
Intel Pentium N3710 processor and 2 GB of dedicated video memory (R5M1-30) 856696-xxx
For use in models with UMA graphics:
●
Intel Core i7-6500U processor 856688-xxx
●
Intel Core i5-6200U processor 856684-xxx
●
Intel Core i3-6100U processor 856683-xxx
●
Intel Core i3-5005U processor 856692-xxx
●
Intel Pentium N3710 processor 856694-xxx
●
Intel Celeron N3060 processor 856695-xxx
(21) Optical Drive Connector Cable Kit 856609-001
(22) DVD+/-RW Double-Layer SuperMulti Drive 756564-037
Optical drive bracket (not illustrated) 856610-001
Optical drive bezel (not illustrated) 856598-001
(23) Battery
4-cell, 41-Whr, 2.8-Ah Li-ion 807957-001
3-cell, 31-Whr, 2.8-Ah Li-ion 807956-001
(24) Bottom cover 856601-001
(25) Rubber Kit 856615-001
20 Chapter 3 Illustrated parts catalog
