HP 1910 Series Datasheet

5
HP 1910 Switch Series
Specifications
HP 1910-48G Switch (JE009A) HP 1910-24G-PoE (365W) Switch (JE007A) HP 1910-24G-PoE (170W) Switch (JE008A)
Ports
48 RJ-45 auto-negotiating 10/100/1000 ports (IEEE
802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX,
IEEE 802.3ab Type 1000BASE-T)
4 SFP 1000 Mbps ports
1 RJ-45 console port to access limited CLI port
Supports a maximum of 48 autosensing 10/100/1000
ports plus 4 1000BASE-X SFP ports, or a combination
24 RJ-45 auto-negotiating 10/100/1000 PoE ports (IEEE
802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX,
IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE)
4 SFP 1000 Mbps ports
1 RJ-45 console port to access limited CLI port
Supports a maximum of 24 autosensing 10/100/1000
ports plus 4 1000BASE-X SFP ports, or a combination
24 RJ-45 auto-negotiating 10/100/1000 PoE ports (IEEE
802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX,
IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE)
4 SFP 1000 Mbps ports
1 RJ-45 console port to access limited CLI port
Supports a maximum of 24 autosensing 10/100/1000
ports plus 4 1000BASE-X SFP ports, or a combination
Physical characteristics
17.4(w) x 10.24(d) x 1.7(h) in (44.2 x 26.01 x 4.32 cm)
(1U height)
17.4(w) x 16.54(d) x 1.7(h) in (44.2 x 42.01 x 4.32 cm)
(1U height)
17.4(w) x 16.54(d) x 1.7(h) in (44.2 x 42.01 x 4.32 cm)
(1U height)
Weight
6.8 lb (3.08 kg) 6.8 lb (3.08 kg) 6.8 lb (3.08 kg)
Memory and processor
ARM @ 333 MHz, 128 MB flash, 128 MB RAM; packet
buffer size: 512 KB
ARM @ 333 MHz, 128 MB flash, 128 MB RAM; packet
buffer size: 512 KB
ARM @ 333 MHz, 128 MB flash, 128 MB RAM; packet
buffer size: 512 KB
Mounting
Mounts in an EIA standard 19-inch telco rack or
equipment cabinet (hardware included)
Mounts in an EIA standard 19-inch telco rack or
equipment cabinet (hardware included)
Mounts in an EIA standard 19-inch telco rack or
equipment cabinet (hardware included)
Performance
100 Mb Latency
< 5 µs < 5 µs < 5 µs
1000 Mb Latency
< 5 µs < 5 µs < 5 µs
Throughput
up to 77.4 Mpps (64-byte packets) up to 41.7 Mpps (64-byte packets) up to 41.7 Mpps (64-byte packets)
Routing/Switching capacity
104 Gb/s 56 Gb/s 56 Gb/s
Routing table size
32 entries (IPv4), 32 entries (IPv6) 32 entries (IPv4), 32 entries (IPv6) 32 entries (IPv4), 32 entries (IPv6)
MAC address table size
8192 entries 8192 entries 8192 entries
Environment
Operating temperature
32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C)
Operating relative humidity
10% to 90%, noncondensing 10% to 90%, noncondensing 10% to 90%, noncondensing
Nonoperating/Storage temperature
-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity
10% to 95%, noncondensing 10% to 95%, noncondensing 10% to 95%, noncondensing
Electrical characteristics
Frequency
50/60 Hz 50/60 Hz 50/60 Hz
Achieved Miercom Certified Green Award
Voltage
100-240 VAC 100-240 VAC 100-240 VAC
Maximum power rating
59.8 W 523 W 255 W
PoE power
365 W 170 W
Notes
Maximum power rating and maximum heat dissipation
are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
Maximum power rating and maximum heat dissipation
are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
PoE power is the power supplied by the internal power
supply. It is dependent on the type and quantity of
power supplies and may be supplemented with the use
of an external power supply (EPS).
Maximum power rating and maximum heat dissipation
are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully
loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
PoE power is the power supplied by the internal power
supply. It is dependent on the type and quantity of
power supplies.
Safety
UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No.
60950-1-03
UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No.
60950-1-03
UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No.
60950-1-03
Emissions
FCC part 15 Class A; VCCI Class A; EN 55022 Class A;
CISPR 22 Class A; EN 55024; EN 61000-3-2 2000,
61000-3-3; ICES-003 Class A
FCC part 15 Class A; VCCI Class A; EN 55022 Class A;
CISPR 22 Class A; EN 55024; EN 61000-3-2 2000,
61000-3-3; ICES-003 Class A
FCC part 15 Class A; VCCI Class A; EN 55022 Class A;
CISPR 22 Class A; EN 55024; EN 61000-3-2 2000,
61000-3-3; ICES-003 Class A
Management
IMC - Intelligent Management Center; limited
command-line interface; Web browser; SNMP Manager;
IEEE 802.3 Ethernet MIB
IMC - Intelligent Management Center; limited
command-line interface; Web browser; SNMP Manager;
IEEE 802.3 Ethernet MIB
IMC - Intelligent Management Center; limited
command-line interface; Web browser; SNMP Manager;
IEEE 802.3 Ethernet MIB
Notes
SFP ports and copper ports work simultaneously,
independent of each other, to provide a total of 52
Gigabit Ethernet-capable ports.
SFP ports and copper ports can work simultaneously,
independent of each other, to provide a total of 28
Gigabit Ethernet-capable ports.
SFP ports and copper ports work simultaneously,
independent of each other, to provide a total of 28
Gigabit Ethernet-capable ports.
Services
3-year, 4-hour onsite, 13x5 coverage for hardware
(UV786E)
3-year, 4-hour onsite, 13x5 coverage for hardware
(UV786E)
3-year, 4-hour onsite, 13x5 coverage for hardware
(UV786E)

HP 1910 Series Specifications

General

PoE Support	No
Type	Managed
VLAN Support	Yes
MAC Address Table Size	8192 entries
Jumbo Frame Support	Yes
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	10% to 90% (noncondensing)
Uplink Ports	4 x SFP
