HP 2311x User Manual

3 Setting Up the Monitor
Unpacking the Monitor
1. Unpack the monitor. Make sure all contents are included. Store the packing box.
2. Turn off the computer and other attached devices.
3. Prepare a flat area to assemble the monitor. You may need a flat, soft, protected area for placing
the monitor screen-down while preparing it for installation.
Assembling the Monitor
Place the monitor in a convenient, well-ventilated location near your computer. Connect the monitor
cables after you have assembled the monitor.
CAUTION: The screen is fragile. Avoid touching or applying pressure to the LCD screen; doing so
can cause damage.
TIP: For monitor displays with glossy bezels, consider the placement of the display, because the
bezel might cause interfering reflections from surrounding light and bright surfaces.
1. Set the monitor panel down on a flat, soft, protected table or desk surface.
2. Slide the pedestal into the slot on the base (1) until the pedestal clicks into the base.
NOTE: The bottom side of the monitor base might look different on your model.
2511x and 2711x models only: Install one screw (2) in the base to secure the pedestal to
the base.
Figure 3-1 Assembling the Base and Pedestal
2
6 Chapter 3 Setting Up the Monitor
Downloaded from ManualMonitor.com Manuals

HP 2311x Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Display diagonal	23 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
HDCP	Yes
USB Type-A downstream ports quantity	0
Product color	Black
Country of origin	China
Tilt angle range	0 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	- mm
Power consumption (standby)	0.6 W
Power consumption (typical)	33 W

Weight and Dimensions

Depth (without stand)	159 mm
Width (without stand)	557.9 mm
Height (without stand)	416.5 mm
Weight (without stand)	3910 g
