Display assembly subcomponents
NOTE: The display assembly is spared at the subcomponent level only. For more display assembly
spare part information, see the individual removal subsections.
A Raw panel support kit is available using spare part number 724299-001.
To remove the display assembly and access the display assembly subcomponents, follow these
steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33) and then remove the following components:
a. Hard drive (see
Hard drive on page 34)
b. WLAN module (see
WLAN module on page 37)
c. Solid-state drive (see
mSATA drive on page 39)
d. Memory module service cover (see
Memory module on page 40)
e. Optical drive (see
Optical drive on page 42)
f. Keyboard (see
Keyboard on page 47)
g. Top cover (see
Top cover on page 50)
h. Fan (see
Fan on page 57)
i. System board (see
System board on page 61)
Remove the display assembly:
1. Release the display panel cable (1) from the clips and routing channel built into the base
enclosure.
2. Release the wireless antenna cables (2) from the clips and routing channel built into the base
enclosure and right display hinge.
3. Remove the six Phillips PM2.5×4.5 screws (3) that secure the display assembly to the top cover.
72 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
