Display assembly subcomponents
Item Component Spare part number
(1) Display bezel (includes insulator screws)
For use in HP Notebook models 813501-001
For use in HP 245 G4 Notebook models 815227-001
(2) Raw display panel (35.6-cm [14.0-in], HD, WLED, BrightView; includes insulator screws)
For use in HP Notebook models without a touch screen 813518-001
For use in HP Notebook models with a touch screen 813520-001
For use in HP 245 G4 models 814811-001
Hinges (left and right; includes insulator screws) 813511-001
(3a) Top hinge
(3b) Left and right hinges
(4) Display cable (includes display panel cable and webcam/microphone cable; includes
insulator screws)
Non-touch screen 813503-001
Touch screen 814042-001
22 Chapter 3 Illustrated parts catalog
