13. cd tboot.hg/txt-test
14. make install (this will create txt-test executable file, run ‘./txt-stat’ to read the serial messages from
the memory buffer. Refer Appendix A for the sample tboot serial output).
15. edit the menu.lst to additional grub entry:
title Fedora Core (Xen 3.3.0 with TXT)
root (hd0,0)
kernel /tboot.gz
module /xen.gz iommu=required com1=115200,8n1 console=com1
module /vmlinuz-2.6.18.8-xen root=LABEL=/ ro console=tty0 console=ttyS0, 115200, 8n1
pci=nommconf (All in a single line. Please note that the ‘console’ parameter will have no effect
here since the unit lacks any serial port)
module /initrd-2.6.18.8-xen.img
module /sinit.bin
16. Make sure to check the root location and ‘root=LABEL=/’ match with the first grub entry and points
to the root partition.
17. Reboot the system. Enable TPM, VTD and TXT in the BIOS settings.
18. The next time you boot into the system, you can select the option at the boot menu to boot into
‘Xen 3.3.0 with TXT’. Copy the latest sinit.bin file into /boot directory.
Note: If the unit hangs after you boot into Tboot at the boot menu, check if you have any USB devices
plugged in to your unit. Also disable USB Legacy Support in your BIOS settings (under F10: System
Configuration Æ Device Configurations Æ USB legacy Support) and try to boot into Tboot again.
TPM TOOLS 1.3.1 Installation
1. Open the terminal
2. cd ~/
3. If required set the proxy options as, export http_proxy=<proxy address>:<port number>
4. Install wget if not already installed (yum install wget)
5. wget http://internap.dl.sourceforge.net/sourceforge/trousers/tpm-tools-1.3.1.tar.gz
6. Make sure you have ‘automake’, ‘autoconf’, ‘libtool’, ‘gettext’ and ‘trousers’ installed.
7. tar –xzvf tpm-tools-1.3.1.tar.gz
8. cd tpm-tools-1.3.1
9. ./configure
10. make
11. make install
LCP: Define Platform Owner Policy
Take TPM Ownership:
1. Open the terminal
2. sudo –s
3. ldconfig (in case of FC8 you may have to try ‘/sbin/ldconfig’)
