9. Release the ZIF connector (3) to which the pointing stick cable is attached, and disconnect the
pointing stick cable (4) from the system board.
10. Remove the keyboard.
11. Disconnect the LED board cable (1) and the power button board cable (2) from the system
board.
12. Remove the switch cover.
Reverse this procedure to install the switch cover and keyboard.
Component replacement procedures 65
