Display assembly subcomponents
Item Component Spare part number
(1) Display bezel (includes Mylar screw covers): 749644-001
(2) Display cable (includes display panel cable and webcam/microphone cable)
Non-touch screen 749646-001
Touch screen 764888-001
(3) Webcam/microphone module 749654-001
(4) Antennas (includes wireless antenna cables and transceivers)
For use in models without a touch screen 749638-001
For use in models with a touch screen 774163-001
(5) Hinges (left and right) 749655-001
For use in models without a touch screen 749655-001
For use in models with a touch screen 774166-001
(6) Raw display panel (39.6-cm [15.6-in], HD, WLED, BrightView)
For use in models without a touch screen 750635-001
For use in models with a touch screen 774167-001
Display assembly subcomponents 19
