3. Remove the heat sink assembly from the system board.
NOTE: Heat sink appearance may vary.
Discrete graphics:
UMA graphics:
●
Discrete graphics: Thermal paste is used on the processor and associated heat sink area (1)(2), as well
as the graphics chip and associated heat sink area (3)(4).
Component replacement procedures 47
