11
Disassembly procedure
ite
m
Picture Operation Tool Notes
1
1.Unlock 4 pcs
screws
Screw-
driver
11±1.0Kgf
2
1.Unlock 1 pcs RC
screws
Screw-
driver
5.0±1.0Kgf
Disassemble the RC
from the monitor,
notice the
disassembly order:
1.Disassemble the
Bottom part
2.Disassemble the
Right part
3. Remove RC from
middle frame.
1
2
3
4
