12
3
1. Remove the CTR
cable and LENS
cable from IF BD
and panel.
2. Remove the 1 pcs
AL tapes and 3
tapes.
3. Remove the lamp
wire and FFC
cable.
4. Remove the SHD.
4
1. Disassemble the
CTR cable and
CTR BD from
middle frame
2. Disassemble the
LENS cable and
LENS BD from
middle frame
