Category Description
WLAN options:
Broadcom 802.11a/b/g/n
Broadcom 802.11a/b/g
Broadcom 802.11b/g
Intel 802.11a/b/g/n with iAMT support
Intel 802.11a/b/g with iAMT support
Intel 802.11b/g
Supports no-WLAN option
Two dual-band 2.4-/5.0-GHz WLAN antennas built into display panel
WWAN options:
Evolution-Data Optimized (EV-DO) Rev. A WWAN module
High-Speed Downlink Packet Access (HSDPA) WWAN module
Subscriber identity module (SIM)
Two 5-band antennas built into display panel
Wireless personal area network (WPAN) options:
Bluetooth® module
Supports no-WPAN option
External media
card
One 54-mm ExpressCard slot
Integrated SD flash media slot (SD/MMC support)
Ports
1394a port
Digital erase pen
Docking connector for HP 3-in-1 NAS Docking Station, HP Advanced Docking Station, HP Docking
Station, and HP External USB 2.0 MultiBay II Cradle
Headphone connector
Microphone connector
Primary battery connector
RJ-11 modem port
RJ-45 Ethernet port
SD card slot (SD/MMC support)
Smart AC adapter connector
Travel battery connector
USB ports (2 ports; one port is powered and is not available when the computer is docked)
VGA port (Dsub 15-pin) supporting 1600 × 1200 external resolution @ 75 Hz, hot plug/unplug, and
auto detect
3
