NOTE:
NOTE: NOTE:
NOTE:
Required for BL20P G3 Fibre Channel signal pass through when using the
CGESM or GbE2 Interconnect Switch.
NOTE:
NOTE: NOTE:
NOTE:
Only one Storage Connectivity Kit required per each GbE2 Interconnect Kit.
NOTE:
NOTE: NOTE:
NOTE:
Only one Storage Connectivity Kit required for (2) CGESM Interconnect Kit.
ProLiant BL p-Class C-GbE Interconnect Kit (with pair of GbE Interconnect Switches
and two QuadT Interconnect Modules)
249655-B21
NOTE:
NOTE:NOTE:
NOTE:
Only one interconnect kit required per server blade enclosure.
NOTE:
NOTE:NOTE:
NOTE:
The GbE Interconnect Switch supports server NIC speeds to 100 Mbps. It is
recommended that a patch panel or GbE2 Interconnect Switch option be used if
server NIC speeds to 1000 Mbps are required.
NOTE:
NOTE:NOTE:
NOTE:
To meet applicable radio frequency (RF) emission limits, the sidewall panels
on the ends of any individual rack or a series of coupled racks and the front and rear
doors must be installed in any racks containing more than one ProLiant BL p-Class
GbE Interconnect Kit.
ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches
and two DualTSX Interconnect Modules)
279720-B21
NOTE:
NOTE:NOTE:
NOTE:
Only one interconnect kit required per server blade enclosure.
NOTE:
NOTE:NOTE:
NOTE:
The GbE Interconnect Switch supports server NIC speeds to 100 Mbps. It is
recommended that a patch panel option be used if server NIC speeds to 1000 Mbps
are required.
NOTE:
NOTE:NOTE:
NOTE:
To meet applicable radio frequency (RF) emission limits, the sidewall panels
on the ends of any individual rack or a series of coupled racks and the front and rear
doors must be installed in any racks containing more than one ProLiant BL p-Class
GbE Interconnect Kit.
HP BladeSystem p-Class
HP BladeSystem p-ClassHP BladeSystem p-Class
HP BladeSystem p-Class
Power Options
Power OptionsPower Options
Power Options
NOTE:
NOTE: NOTE:
NOTE:
Use p-Class sizing tool to help determine power configuration:
http://h30099.www3.hp.com/configurator/powercalcs.asp
Single Phase 3U Power Enclosure with 4 power supplies
(Single Phase 3U Power Enclosure holds a maximum of 4 power supplies; no need to
order additional power supplies with this option kit)
239162-001
3 Phase 3U Power Enclosure with 6 power supplies
(3 Phase 3U Power Enclosure holds a maximum of 6 power supplies; no need to
order additional power supplies with this option kit)
230769-001
Single Phase 3U Power Enclosure (empty)
(Holds up to 4 power supplies; power supplies are not included in this kit)
231710-001
3 Phase 3U Power Enclosure (empty)
(Holds up to 6 power supplies; power supplies are not included in this kit)
231709-001
Single 3U Power Supply
239161-B21
1U Power Enclosure with six power supplies
378284-B21
1U Power Enclosure with two power supplies
380314-B21
Single 1U Power Supply
380312-B21
Facility DC Power Connection
240563-B21
QuickSpecs
HP ProLiant BL25p Server Blade
HP ProLiant BL25p Server BladeHP ProLiant BL25p Server Blade
HP ProLiant BL25p Server Blade
Options
DA - 12160 North America — Version 7 — June 27, 2005
Page 28
