12. Mechanical Instructions
Step Figure Description
Remove
the
STAND.
The model
using the
curved surface
screen; There
must be put soft
mat above of
the work station
and don't push
hard on the
machine to
avoid cause
screen to crack.
Remove the
screws to
remove the
stand-base
assy.
Remove
the rear
cover
Use
disassembly
tool to open all
the latches
along the edge
of the Rear
Cover
