EL-MF877-00 Page 9
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step20 Use PH1 screwdriver to loose
screws from PSU
Step21 Open the PSU cage and use PH1
screwdriver to loose the screw of PCBA
cable
Step22 Use PH1 screwdriver to loose
screws and remove PCB from case
