Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For display assembly spare
part information, see
Display assembly subcomponents on page 20.
(2) Keyboard in charcoal finish (includes keyboard cable):
For use in HP 3115m models:
●
For use in Canada 659500-121
●
For use in Latin America 659500-161
● For use in the United States 659500-001
For use in HP 3125 models:
●
For use in Canada 699028-DB1
● For use in Latin America 699028-161
●
For use in the United States 699028-001
(3) Top cover in charcoal finish (includes power button board and cable and TouchPad
and TouchPad cable):
659513-001
(4) Speakers (includes cables) 659508-001
(5) TouchPad button board (includes cable) 664993-001
(6) System board (includes processor and replacement thermal material):
For use in HP 3115m models:
● AMD E450 processor and WWAN capability 659512-001
●
AMD E450 processor without WWAN capability 659511-001
●
AMD E300 processor and WWAN capability 659510-001
● AMD E300 processor without WWAN capability 659509-001
For use in HP 3125 models:
●
AMD E2-2000 processor without WWAN capability and without Windows 8 702958-001
● AMD E2-2000 processor without WWAN capability with Windows 8 Standard 702958-501
●
AMD E2-2000 processor without WWAN capability with Windows 8 Professional 702958-601
●
AMD E2-2000 processor with WWAN capability without Windows 8 702959-001
● AMD E2-2000 processor with WWAN capability and with Windows 8 Standard 702959-501
●
AMD E2-2000 processor with WWAN capability and with Windows 8
Professional
702959-601
●
AMD E1-1500 processor without Windows 8 702960-001
●
AMD E1-1500 processor with Windows 8 Standard 702960-501
● AMD E1-1500 processor with Windows 8 Professional 702960-601
(7) Power connector cable (includes bracket) 664995-001
(8) Heat sink (includes replacement thermal material) 664999-001
(9) Fan 665000-001
18 Chapter 3 Illustrated parts catalog
