Display panel

Description Spare part number

11.6-in, LED, HD, BrightView SVA display panel 668353-001

Before removing the display panel, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet

and then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 33).

5. Remove the service cover (see

WLAN module on page 38).

Remove the display panel:

1. Turn the computer right-side up, with the front toward you.

2. Open the computer.

3. Flex the inside edges of the top edge (1), the left and right sides (2), and the bottom edge (3) of

the display bezel until the bezel disengages from the display enclosure.

4. Remove the display bezel (4). The display bezel includes the display hinge covers and the lid

switch magnet and is available using spare part number 669025-001 for model HP 3115m and

714296-001 for model HP 3125.

5. Remove the four Phillips PM2.0×3.6 screws (1) that secure the display panel to the

display enclosure.

6. Swing the top edge of the display panel (2) forward until it rests on the keyboard.

Component replacement procedures 35
