g. Remove the display panel cable (3). The display panel cable is available in the Display

Cable Kit, spare part number 659498-001.

8. If it is necessary to replace the wireless antenna cables and transceivers:

a. Remove the display assembly.

b. Remove the display bezel.

c. Remove the display panel.

d. Remove the display hinges.

e. Remove the Phillips PM2.0×4.2 screw (1) that secures the right enclosure bracket to the

display enclosure.

f. Remove the left and right enclosure brackets (2). The left and right display enclosure

brackets are included in the Display Hinge Kit, spare part number 659499-001.

g. Release the wireless antenna cables (3) from the clips (4) and routing channels built into

the display enclosure.

h. Detach the WLAN transceivers (5) from the display enclosure. (The transceivers are

attached to the display enclosure with double-sided tape.)

Component replacement procedures 55
