HP 3150 - Page 132

130 Removal and replacement
EN
3 Remove the four (4) screws (callout 1) from the back sheet metal
plate and lift it off.
4 Remove the four (4) screws (callout 2) from the paper feed frame.
Figure 58. Paper feed frame removal (2 of 3)
2
1
2
2
2
2
