HP 3314A - Page 35

Model 3314A
Operation
THE 3314A REAR PANEL
X3 output
(only Instruments with Option 001 have
this output) IS a high voltage, low impedance out-
put whose output voltage
IS
3 times the displayed
amplitude and offset when the Main Output
IS
ter-
minated Into 50n, This output whose capable of
sourcinq
±
30mA peak current without clipping
The upper frequency limit
IS
1 MHz,
X Axis output produces a voltage ramp from -5V
to
+
5V whose voltage
IS
proportional to the sweep
frequency This output
IS
useful to drive the
X
A~ls
of plotters and oscilloscopes,
Z Axis output produces voltage levels to blank
(>
+
5V!or enhance l<,-5V~ the intensity of an
oscilloscope display durinq sweep (intensifies the
marker frequency and blanks the retrace] or ARB
(intensifies the current vector).
HP-IB
IS
used to control the operating of the 3314A
from a remote controller, This connector uses
metric fasteners and
IS
not compatible With older
cables usinq english threated fasteners, Metric
fasteners are available from -hp- to upgrade older
cables
Figure 3-1a. 3314A Rear Panel
3-3
