200 Removal and replacement ENWW
Print cartridges and transfer unit
It is recommended that you remove the print cartridges and transfer unit when servicing internal
printer components. Place the print cartridges and transfer unit in a safe place while they are out of
the printer.
CAUTION Grasp the print cartridges by the blue handles to avoid accidentally touching the photosensitive drum
inside each cartridge.
Do not place any items on the transfer unit or touch the transfer belt. If the belt is punctured or
otherwise damaged, print quality problems will result.
For instructions on removing the transfer unit, see Transfer unit removal and for instructions on
removing the print cartridges, see Print cartridge removal.
