PDH / DSn Testing With The HP 37717C
Alarm Monitoring
1 Connect the HP 37717C to the line
terminal equipment protected Monitor
point and set up the display
as shown opposite.
The GAIN and EQUALIZER settings
should be set to optimize the received
signal.
2 Set up the display
as shown
opposite.
2M PAYLOAD determines the Framing
and selection which should match that of
the network equipment.
RECEIVE
MAIN SETTINGS
RECEIVE
STRUCTURED SETTINGS
To Next Page
