DST SOFTKEY LABEL: NOT ASSIGNED
The DST command starts the data continuous output mode.
SYNTAX:
( DST
IMPORTANT POINTS:
When "UNBAL" is displayed on the LCD, the output data returned is
2.00000E20. When "" is displayed on the LCD, the output data
returned is the measured value.
EXAMPLE:
10 OUTPUT 717;"TRIG2"1 Set the TRIG MODE to EXT TRIG
20 OUTPUT 717;"DST"! Start the data continuous mode
30 FOR 1=1 to 10
40 OUTPUT 717;"•TRG"! Trigger the 4278A
50 ENTER 717;C:D1 Read the 4278A's data
60 PRINT C,D! Display the readings
70 NEXT 1
80 OUTPUT 717;"DEND1 End the data continuous mode
90 END
When you run the above program data is returned and displayed ten
times.
DSTD= SOFTKEY LABEL: D. (in TO,V1PEN')
The DSTD= command sets the standard compensation reference value
(0)•
SYNTAX:
value
VALUE:
)1
You can not use a suffix (for example: m (milli)), with the reference
value.
EXAMPLE:
OUTPUT 717;"DSTD=0.0002"1 Set the °STD to 0.0002
4-28
