RECOMMENDED TEST EQUIPMENT
Table 1-2 lists the equipment required for performance testing the analyzer. Other equipment
may be substituted if the equipment meets or exceeds the critical specications given in
Table 1-2 .
Table 1-2. Recommended Test Equipment
Equipment Critical Specications Recommended Model/
HP Part Number
Qty
Frequency Counter Frequency Range: 500 MHz,Time Base Error:
6 1.9 2 10
0 7
/year
HP 5334B
1
1
Frequency Standard
2
Frequency: 10 MHz,Time Base Error: 
6 1 2 10
0 10
/year
HP 5061B 1
Spectrum Analyzer Frequency Range: 100 Hz to 1.5 GHz HP 8566A/B 1
Network Analyzer Frequency Range: 300 kHz to 500 MHz HP 8753C/D 1
Power Meter No substitute HP 436A Opt. 022 , HP 437B,
or HP 438A
1
Power Sensor Frequency Range : 1 MHz to 500 MHz,Power:
0 26 dBm to 0 dBm
HP 8482A 1
Power Sensor Frequency Range : 1 MHz to 500 MHz,Power:
0 60 dBm to 0 35 dBm
HP 8481D 1
Function Genarator Frequency Range : 10 Hz to 500 kHz, Level
Accuracy: 6 0.2 dB,Return loss: > 20 dB
HP 3325A/B 1
Multimeter No substitute HP 3458A 1
Signal Generator Frequency Range : 1 MHz to 500 MHz, SSB
Phase Noise at 100 Hz oset: < 0 112 dBc/Hz,
SSB Phase Noise at 1 kHz oset: < 0 121
dBc/Hz
HP 8663A 1
Signal Generator Frequency Range : 50 MHz to 100.2 MHz, SSB
Phase Noise at 100 Hz oset: < 0 112 dBc/Hz,
SSB Phase Noise at 1 kHz oset: < 0 121
dBc/Hz
HP 8642B 1
Step Attenuator
3
Attenuation Range : 0 dB to 100 dB, Step: 10
dB,VSWR:  1.02
HP 8496G Opt. 001 and
H60
4
1
Attenuator/Switch
Driver
No substitute HP 11713A
5
1
50 Type-N Calibration
Kit
No substitute HP 85032B 1
T/R Test Sets Frequency Range: 300 kHz to 500 MHz,
Directivity:  40 dB
HP 85044A 1
50 MHz Low Pass Filter Rejection at 75 MHz:  60 dB PN 0955-0306 1
50  Feedthrough Rejection at 75 MHz:  60 dB PN 04192-61002 1
Termination 50 Termination, type-N(m) HP 909C Opt. 012 or part of
HP 85032B
6
3
