Clearing Jams
31
3
Clearing Jams in the Rear Doors Area
WARNING!
Do not touch the fuser: it is hot! The fuser’s operating
temperature is 190° C (374° F). Wait 30 minutes to allow the
fuser to cool down before working in this area.
1
If the duplex printing accessory is installed, open the rear
duplex cover (1).
2
Open the upper rear door (2).
3
Inspect the upper paper path area (3) inside the rear door
and remove all jammed or torn media.
4
Inspect the fuser area (4) for jammed media.
5
Close the rear door.
6
If the duplex printing accessory is installed, inspect the
duplexing area and remove all jammed or torn media.
7
Close the rear duplex cover. The printer will warm up and
return to the READY state.
