HP 15” Color Monitor User’s Guide
Technical Specifications
Technical Specifications
PICTURE TUBE
Size 15-inch flat screen/ 13.8-inch viewable image
Phosphorous Red, Green, Blue P22 (medium short persistence)
Dot pitch 0.28 mm
Face Plate Anti-glare, anti-static, silica coating
INPUT SIGNAL
Video 0.7 Vp analog RGB
Synchronization TTL level separate synchronisation (negative/positive)
INTERFACE
Input Connector 15-pin mini D-SUB
SCANNING FREQUENCY
Horizontal 30 to 54kHz
Vertical 50 to 120 Hz
WARM-UP TIME
30 minutes to reach optimum performance level
PIXEL CLOCK
65 MHz
DISPLAY SIZE
283
×
212mm (maximum size)
POWER SOURCE
100-240 Vac / 50-60Hz. 75W max.
OPERATING ENVIRONMENT
Temperature 10
°
C to 40
°
C (operating)
Humidity 20% RH through 90% RH (without condensation)
STORAGE ENVIRONMENT
Temperature
-20
°
C to +60
°
C
Humidity
10% RH through 95%RH
CABINET DIMENSIONS
376(W)
×
373(H)
×
385(D) mm (including pedestal)
WEIGHT
12.5 kg (27.5 lbs)
TILT/SWIVEL STAND
Tilt Angle - 5
°
to +15
°
Swivel Angle -45
°
to +45
°
