HP 5200L Series

Walkaround
Printer parts
Before using the printer, familiarize yourself with the parts of the printer.
5
1
2
3
4
7
6
1 Top output bin
2 Long-media extension
3
Latch to open the front cover (provides access to the print cartridge)
4
Tray 1 (pull to open)
5 Tray 2
6 Control panel
7 Right-side cover (provides access to DIMMs)
