32
HDMI connector P200
524sf, 524sw, 524sh, 524sa, 527sf, 527sw, 527sh, 527sa
Repair the HDMI connector:
1) Use a soldering iron and a desoldering pump to remove as much solder as possible from the pin.
2
) Use a soldering iron or hot air gun to melt the solder on the pins.
3
) Lift the P200 connector from the PCB.
4) Place the new component on the PCB. Be sure that it matches the PCB footprint.
5) Solder the new component.
