Model 5305B General
Information
Table 9E-1-2. Recommended Test Equipment
Instrument Required Characteristics Recommended Type
Oscilloscope 50 MHz Bandwidth HP 180A
Vertical Plug-In 50 mV/div Sensitivity HP 1801A
Time Base Plug-In 50 MHz Bandwidth HP 1821A
Sampling Plug-In 1000 MHz HP 1810A
Optical Sampling Plug-In If desired to measure up to 1300 MHz HP 1811A/1432A
Synthesized Signal Generator 1300 MHz HP 8660B/86602A
Power Meter -30 dBm to + 10 dBm HP 435A
Power Sensor 90 MHz to 1300 MHz HP 8481A
Test Oscillator 50 Hz to 10 MHz 3V rms HP 651B
Mainframe HP 5300B
Digital Voltmeter -5V to +20 V dc HP 5306A
Power Splitter 50 ohms 90 MHz to 1300 MHz HP 11667A
Scope Probe 10:1 1 MegΩ HP 10004D
