HP 5384A
and
HP 5385A
Performance
Tests
Table 4-1. Performance
Test
(Continued)
2.
Set
the
HP
86408 Signal
Generator
so
the
HP
436A Power
Meter
reads -17.5 dBm
at
90
MHz
.
Increase
the
frequency
of
the
signal generator
while
maintaining
a
-17.5dBm
reading
on
the
power
meter. Verify
the
HP 5385A displays an increase
in
frequency,
approximately
tracking
the
signal
generator
from
90
MHz
to
100
MHz.
Record
the
results
on
the
test card (Pass/Fail).
b. 100
MHz
to
1000
MHz
1.
Set
the
HP
86408 Signal Generator
so
the
power
meter
reads -21 dBm
at
100
MHz.
Increase
the
frequency
of
the
signal generator
while
maintaining
a -21
dBm
reading
on
the
power
meter, and verify
the
HP
5385A
displays
the
proper
frequencies
from
100
MHz
to
1000
MHz.
Record
the
results
on
the
test card (Pass/Fail).
V.
PERIOD A TEST
Description:
A signal
generator
with
a calibrated
output
drives channel A
of
the
HP 5384A/HP 5385A
under
test. The
counter
is
set
to
measure
the
period
of
the
signal. The
HP
5384A/HP 5385A should display
the
proper
count.
Specifications: 10 nanoseconds
to
0.1
seconds
(100
MHz
to
10Hz)
a.
Connect
the
HP 3325A
synthesizer/function
generator
to
the
HP
5384A/HP 5385A Channel A
input
as
shown in Figure 4-5.
BNC
"T"
CONNECTOR
I EXT
REF
IN OVEN
OUTPUT
EXT
10
MHz
HP
5384A/HP
5385A
REF FREQUENCY COUNTER
nn
Ll
I 1
:~Hi0;,00:;:;
r-:H
zJII
~I
I~~~~~~~~~~~~
IT
@
I INPUT A
I
~
HP
10100C
son
FEEDTHROUGH
r..
·l
fillil
~~
0 0
00000
00000
00000
00000
HP 3325A
SYNTHESIZER/FUNCTION
GENERATOR
(OPTION
001)
BNC
CABLE
Figure
4-5.
Period A
Test
Setup
RF
OUTPUT
b.
Set
the
counter
power
switch
from
STBY
to
ON
and select PERIOD A. Set
the
GATE
time
to
1.0
seconds.
c.
Set
the
HP 3325A synthesizer
to
10 Hz
at
100
mV
rms
output.
d. Verify
the
counter
displays 100.00000 milliseconds ±70 microseconds. Record
the
results
on
the
test card (pass/fail).
VI.
CHANNEL
A FILTER AND ATTENUATOR TEST
Description:
A signal
generator
with
a calibrated
output
drives
the
channel A
of
the
HP
5384A
or
HP
5385A
under
test. The
counter
is
set
up
for
its Frequency A
function,
and
the
channel A
filter
is
exercised
at
frequencies
below
and above its
normal
3 dB
point.
The channel A
attenuator
is
also exercised. The
counter
should
display
the
proper
frequencies.
4-5
