HP 6000 Hardware Reference Guide

Front Panel Components
Drive configuration may vary by model.
Table 1-1 Front Panel Components
1 5.25-inch Optical Drives
1
6 Optical Drive Eject Buttons
2 Optical Drive Activity Lights 7 3.5-inch Media Card Reader (optional)
2
3 Hard Drive Activity Light 8 Dual-State Power Button
4 Microphone/Headphone Connector 9 Power On Light
5 USB (Universal Serial Bus) 2.0 Ports 10 Headphone Connector
NOTE: When a device is plugged into the Microphone/Headphone Connector, a dialog box will pop up asking if you
want to use the connector for a microphone line Line-In device or a headphone. You can reconfigure the connector at
any time by double-clicking the Realtek HD Audio Manager icon in the Windows taskbar.
NOTE: The Power On Light is normally green when the power is on. If it is flashing red, there is a problem with the
computer and it is displaying a diagnostic code. Refer to the Troubleshooting Guide to interpret the code.
1
Some models have bezel blanks covering one or both of the 5.25-inch drive bays.
2
Some models have a bezel blank covering the 3.5-inch drive bay.
2 Chapter 1 Product Features ENWW

HP 6000 Specifications

General

Audio	Integrated High Definition Audio
Processor	Intel Core 2 Duo
RAM	Up to 8GB DDR3
Storage	Up to 1TB HDD
Graphics	Integrated Intel Graphics Media Accelerator 4500, Optional discrete graphics cards
Operating System	Windows 7
Optical Drive	DVD-ROM
Network	Integrated 10/100/1000 Ethernet
Ports	USB 2.0, VGA, Serial, Parallel, PS/2, Audio In/Out
Expansion Slots	PCI, PCIe x1, PCIe x16
Power Supply	300W
