Category Description
Supports “no camera” option
Stereo Speakers (2)
Serial port RS-232 /Serial Port
Supports "no serial port" option”
Ethernet Realtek RTL8111HSH Gigabit Ethernet NIC with DASH Support
The following support HBMA (via UEFI PXE boot and Windows OS):
embedded NIC, Quest, HP3005, Ace Plus, Bert, and Ernie
The following dongles only support S3 wake on LAN: Ace Plus
S3/S4/S5 wake on LAN
15” models only:
Realtek RTL8111HSH Gigabit Ethernet
The following dongles only support S3 wake on LAN (via HBMA PXE and
Windows OS): Scooby, Ace, Bert, Speedy, and Hotdog
Wireless LAN WPAN Bluetooth:
BT 4.0 only supported via Realtek Sanji2
BT 4.2 only supported via Intel Sandy Peak non-vPro and Intel Stone Peak 2
non-vPro
WLAN:
WLAN options via Minicard:
Intel 802.11 ac 1x1 + BT 4.2 Combo (Sandy Peak 1 non-vPro)
ntel 802.11 ac 2x2 WiFi + BT 4.2 Combo (Stone Peak 2 non-vPro)
Realtek RTL8723BE-VB 802.11b/g/n 1x1 Wi-Fi + BT4.0 Combo (Sanji2)
WLAN Antennas (2) (congured at top of panel on all units)
Bluetooth Disabled IOPT
Support "No WLAN/No BT" option
Support for Miracast
Support for HP Sure Connect
NFC (select products only)
Integrated NFC Galapagos NXP NPC100 I2C NCI 10mmx25mm module
NFC Antenna (congured on NFC SKUs only)
NFC Cable
Supports "No NFC" option
Wireless WAN (select products only) SIM Module (3FF/micro SIM): (user accessible on side of unit)
WWAN options via connector:
Foxconn HP lt4120 LTE/EVDO/HSPA+ w/GPS M.2 (Amstel)
Huawei HP lt4132, LTE/HSPA+ w/GPS M.2 (Macan)
Fibocom HP hs3210 WW HSPA+ w/o GPS (Wrangler 2)
3
