Item Component Spare part number
NOTE: For spare part information, see Mass storage devices on page 29.
(17) Speaker (includes cable) 840700-001
(18) Audio board (includes cable) 917458-001
(19) Base enclosure
For 14" products 840657-001
For 15" products 840725-001
(20) Solid-state drive
NOTE: For spare part information, see Mass storage devices on page 29.
(21) Serial port (includes cable) (select products only) 840746-001
(22) Hard drive
NOTE: For spare part information, see Mass storage devices on page 29.
(23) Memory
4GB 2133MHz 1.2v DDR4 shared memory 820569-002
8GB 2133MHz 1.2v DDR4 shared memory 820570-002
(24) WLAN module
Realtek 11BGN+BT4 1x1 SANJI2 CB 855106-852
11AC+BT 1x1 3168.NGWG M.2 MOW 863934-852
11AC+BT INT 7265NV M.2 D1 MOW 901229-852
11AC 2x2 INT 8265NGWMG 910264-852
11AC 2x2 INT 8265NGWMG.NV 918855-852
(25) WWAN module (select products only)
T77W595 LTE M.2 with GPS 800870-002
Huawei Wrangler 2 HSPA+M.2 918670-852
Macan ME906S LTE with GPS M.2 918671-852
(26) Battery—3-cell HP Long Life Prismatic 48 WHr ( 4.21 Ahr ) 801554-001
(27) Optical drive
NOTE: For spare part information, see Mass storage devices on page 29.
(28) Service door
For 14" products 840657-001
For 15" products 840725-001
26 Chapter 3 Illustrated parts catalog
