3. If it is necessary to disassemble the hard drive, remove the 4 screws (1), and then remove pull the tab
(2) to remove the cover from the hard drive.
Reverse this procedure to reassemble and install the hard drive.
Solid-state drive (select products only)
Description Spare part number
Solid-state drive
360 GB PCle TLC 922249-001
128 GB M2 SATA-3 Value 922250-001
256 GB Turbo G2 TLC 922251-001
256 GB SATA-3 self-encrypting drive Opal2 TLC 922252-001
512 GB Turbo G2 TLC 922253-001
512 GB Turbo G2 self-encrypting drive Opal2 TLC 922254-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal and
replacement
Before removing the solid-state drive, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
Component replacement procedures 41
