2. With the memory module at a 45-degree angle from the surface of the memory module compartment,
press the module (2) into the memory module slot until it is seated.
3. Gently press the memory module down, applying pressure to both the left and right edges of the
memory module, until the retention clips snap into place.
CAUTION: To prevent damage to the memory module, be sure that you do not bend the memory
module.
52 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
