d. Solid-state drive (see Solid-state drive (select products only) on page 41).
e. WWAN module (see WWAN module (select products only) on page 42).
f. WLAN module (see WLAN module on page 43).
g. Optical drive (see Optical drive on page 45).
h. Keyboard (see Keyboard on page 47).
i. Hinge covers (see Hinge cover on page 53).
j. Base enclosure (see Base enclosure on page 55).
k. System board (see System board on page 57).
l. Fan/heat sink assembly (see Fan and heat sink assembly on page 59).
m. Top cover (see Top cover and TouchPad on page 63).
Remove the smart card reader:
▲
Remove the metal shield, and then lift the smart card reader to remove it.
Reverse this procedure to install the smart card reader.
Component replacement procedures 73
