Plastics Kit
Item Description Spare part number
Plastics Kit: 487429-001
(1) Hard drive bay cover (includes 2 captive screws, secured by C-clips)
(2) Memory module compartment cover (includes one captive screw, secured by a C-clip)
(3) ExpressCard slot bezel
(4) WWAN module compartment cover (includes one captive screw, secured by a C-clip)
(5) Bluetooth module compartment cover (includes one captive screw, secured by a C-clip)
26 Chapter 3 Illustrated parts catalog
