Model8756A
Item
2
3
4
INSTALLATION INSTRUCTIONS
1. REMOVE SIDE TRIM STRIPS 1.
2. ATIACH FRONT HANDLE ASSEMBLY 2 WITH FOUR 8-32 x 3/8 SCREWS 3 PER SIDE.
3. PRESS FRONT HANDLE TRIM 4 IN PLACE.
Qty.
2
6
2
OPTION 907 (HP Part No. 5061-0090) CONTENTS
HP Part No.
5060-9900
2510-0195
5020-8897
c
D
0
6
8
Description
Front Handle Assembly
#8-32 x 3/8 Screw
Front Handle Trim
Figure 2-5. Option 907 Front Handles Kit
Installation
2-9
