HP 8756A - Page 15

Model8756A
Item
2
3
4
INSTALLATION INSTRUCTIONS
1. REMOVE SIDE TRIM STRIPS 1.
2. ATIACH RACK MOUNT FLANGE 2 AND FRONT HANDLE ASSEMBLY 3 WITH FOUR 8-32 x 5/8
SCREWS 4 PER SIDE.
3. REMOVE FEET AND TILT STANDS 5 BEFORE RACK MOUNTING.
Qty.
2
2
6
OPTION 909 (HP Part No. 5061-0084) CONTENTS
HP Part No.
5020-8875
5060-9900
2510-0194
c
D
2
0
8
Description
Rack Mount Flange
Front Handle Assembly
#8-32 x 5/8 Screw
Figure 2-7. Option 909 Rack Mount Kit with Handles
Installation
2-11
