HP 8756A - Page 29

General Information Mode18756A
Table 1-3. Recommended Test Equipment(2 of2)
Instrument
Critical Specifications
Recommended Model
Use*
Logic Pulser TIL Compatible
HP 546A T
(HP 10526T)
Current Tracer TIL Compatible
HP 547A T
Compatible with Logic Pulser
Service Kit No Substitute
HP PIN 087 56-60020 T
(Equipment below required for Calibration Constants Adjustment Procedure only)
Modulator
On/Off Ratio: 2:: 30 dB at 50 MHz
HP ll665B
A,T
Modulation Rate: 27.778 kHz
Controller
Personal Computer
HP85F
A,T
(No Substitute)
Printer/Plotter ROM Compatible with Controller
HP P /N 00085-15002
A,T
Advanced Programming Compatible with Controller
HP PIN 00085-15005
A,T
ROM
16K Memory Module
Compatible with Controller
HP 82903A
A,T
"CAL56A" Program Tape No Substitute
HP PIN 08756-10001
A,T
Adapter
N(f) to N(F)
HP P/N 1250-1472
A,T
Adapter
N(m) to N(m)
HP P/N 1250-1475
A,T
Band Pass Filter CF =50 MHz, BW = 10 MHz
Te1onic P/N 50-10-2-EF
A,T
Rejection >20 dB at 20 MHz
>20 dB at 100 MHz
SWR~1.2
1-10
