6. Remove the 2.5” drive if one is installed. Disconnect the cable from the rear of the drive (1), pull the arm
back at the rear of the drive (2), and then slide the drive back and lift it out of the drive bay (3).
7. To remove an M.2 storage device, remove the screw that secures the device to the system board (1) so
that the end pops up (2), and then slide the device out of the connector (3).
NOTE: Due to the small size of the screw, a magnetized screwdriver may be helpful to remove the
screw.
Removing and installing an M.2 storage device 31
