7. Unclip one wire clip (callout 8), disconnect four connectors (callout 9) and remove one grounding
screw and wire (callout 10).
8
9
10
Figure 5-71 Removing the ADF cable (5 of 5)
8. Remove the ADF cable.
ENWW Internal components 91
