Table 7-7 ADF Assembly
Reference Description Part Number Quantity
1 ADF assembly PF2284-SVPNI 1
2 ADF right cover corner PF2284P079NI 1
3 ADF right cover PF2284P044NI 1
4 White scan background PF2282P339NI 1
5 White mylar backing PF2282P025NI 1
6 White mylar backing springs PF2282P343NI 2
7 ADF rear cover PF2284P086NI 1
8 Screw, ADF, wave 3x10 NS-SCR-00027NI 40
9 Upper hinge cover PF2284P088NI 2
10 Screw, ADF, 03T060SR-W NS-SCR00016NI 17
11 Screw, ADF 030080FWWSNI 4
12 Screw, ADF, wave 4x10 NS-SCR-00056NI 7
13 Screw, ADF, 3x6 w/washer 030060FWWSNI 18
14 ADF cable PF2284K500NI 1
ENWW ADF components 171
