Table 7-8 ADF base assembly
Reference Description Part Number Quantity
1 Damper base cover PF2284P091NI 2
2 Left damper spring PF2284P375NI 2
3 Right damper spring PF2284P376NI 1
4 Damper cover PF2284P090NI 2
5 Output bin paper lever PF2284P089NI 1
6 Output bin extender PF2284P061NI 1
7 Output bin base cover PF2284P060NI 1
ENWW ADF components 173
