HP 9250C Digital Sender - Separation Pad Replacement

Separation pad
1. Open the ADF top cover.
1
2
Figure 5-1 Removing the separation pad (1 of 3)
2. Raise the separation pad frame assembly.
Figure 5-2 Removing the separation pad (2 of 3)
ENWW User-replaceable parts 39
