PCI 1-port UltraSCSI differential adapter (uses one PCI slot); includes external 68-
pin HD connector, requires BN38C-xx cable (2 to 25 meter) to connect adapter to
differential UltraSCSI shelf or RAID controller
4 4
3X-KZPBA-CC
68-pin HD male-to-VHDCI male UltraSCSI cable;
xx = 02, 03, 05, 10, 20, 25 meter
BN38C-xx
PCI 2-port PCI to Ultra3, 64-bit, 66 MHz, LVD backplane RAID controller with
128-MB cache (uses one PCI slot); requires connection to DS-SL13R-xx shelves or
BA610-6D card cage.
NOTE:
NOTE: NOTE:
NOTE:
No host-based volume shadowing or shared bus support with OpenVMS.
4 4
3X-KZPDC-BE
PCI 4-port PCI to Ultra3, 64-bit, 66 MHz, LVD backplane RAID controller with
256-MB cache (uses one PCI slot); requires connection to DS-SL13R-xx shelves or
BA610-6D card cage.
NOTE:
NOTE: NOTE:
NOTE:
No host-based volume shadowing or shared bus support with OpenVMS.
4 4
3X-KZPDC-DF
U320 LVD SCSI Backplane Raid Controller, 64 bit, 2 Channel
-
4
3X-KZPEC-BF
U320 LVD SCSI Backplane Raid Controller, 64 bit, 4 Channel
-
4
3X-KZPEC-DG
Step 9 – M-series Cabinets or Rack 10000 Series
Step 9 – M-series Cabinets or Rack 10000 SeriesStep 9 – M-series Cabinets or Rack 10000 Series
Step 9 – M-series Cabinets or Rack 10000 Series
Step 9a – M-Series Cabinet – Optional
Step 9a – M-Series Cabinet – OptionalStep 9a – M-Series Cabinet – Optional
Step 9a – M-Series Cabinet – Optional
M-series enclosures require selection of the following items:
H9A10 or H9A15 cabinet
Rack kit for each system
H9A10 or H9A15 rear cabinet extender
Second PDU required with four or more systems in one cabinet
Cabinet front door based on cabinet height
Factory integration
Ballast kit if two or less systems are ordered for the H9A15 cabinet
Two power cords for each system
NOTE:
NOTE: NOTE:
NOTE:
For more information on M-Series Cabinet Enclosures, see
http://www.compaq.com/alphaserver/products/m-series/specs.html
Cabinet Configuration Chart for AlphaServer DS25 (5U) with DS-SL13R (3U) StorageWorks Shelves
Cabinet Configuration Chart for AlphaServer DS25 (5U) with DS-SL13R (3U) StorageWorks ShelvesCabinet Configuration Chart for AlphaServer DS25 (5U) with DS-SL13R (3U) StorageWorks Shelves
Cabinet Configuration Chart for AlphaServer DS25 (5U) with DS-SL13R (3U) StorageWorks Shelves
QuickSpecs
HP AlphaServer DS25 HP AlphaStation DS25
HP AlphaServer DS25 HP AlphaStation DS25HP AlphaServer DS25 HP AlphaStation DS25
HP AlphaServer DS25 HP AlphaStation DS25
Options
DA - 11432 Worldwide — Version 21 — May 7, 2007
Page 11
