72
push- wheel decimal)
nnnnnnnn
network number (10
decimal)
network number (10
decimal)
network number (10
decimal)
mmmmm
mmm
MBM in cab0, 1-4
MBM in cab1, 11-14
254 See special addresses
pppppppp
0 for MBM,
1-4 for CMM
PBM push-wheel See special addresses
eeeeeeee
0 for CMM itself,
1-2 for EV7 ID,
when MBM specified,
default = 1
Cabinet ID push-
wheel
See special addresses
Some examples
Device
Comment
MBM 10.1.0.1 MBM cabinet ID 0, drawer ID 1 (eeeeeeee default =
1)
PBM 10.254.1.0 PBM cabinet ID 0, drawer ID 1
CMM 10.2.1.0 CMM #1 connected to MBM 2
EV7 10.2.1.2 second EV7 connected to CMM 1 connected MBM 2
Special Addresses
Address Comment
PMU server 10.253.0.1 Address used to get to the PMU
Route for NXMs 10.253.0.2 default address for addresses not in
the proper range of addresses
Telnet server 10.253.0.3 Dedicated address for a telnet session
DHCP addresses 10.253.0.4-253 DHCP address pool
Dedicated PMU address 10.253.0.254 For VMS use
