2013 HP UltraSlim Docking Station - D9Y32AA#XX
Front Components
Docking posts (2)
Align and secure the computer for proper connection to the docking station
Computer connect/
release mechanisms (2)
Connect and release the computer when you press the connection button
Docking connector
Docking connector for notebook
Connect button
Secures and releases the computer
Slide in to secure the computer
Slide out to release the computer
LEDs
AC present: aqua white; Dock connected: white; two RJ45 LEDs: amber/green
Rear Components
AC power port
Energy-efficient 65W Smart AC adapter features integrated surge protection to help against power
fluctuations.
Integrated cable lock slot
Supports the HP Docking Station Cable Lock with a simplified locking mechanism. Gives you two security
options: lock the docking station only (which also prevents access to the Station drive bay); or lock both
the docking station and your notebook for additional security. Also supports an industry standard
notebook lock.
Network connectors
RJ-45 / Ethernet pass thru
USB ports
3 USB 3.0 ports, 1 USB 3.0 charging port
Audio connectors
Line-In; Line-Out
Other connectors
VGA, DisplayPort 1.1a (DP 1.2 capable)
NOTE:
Your computer, docking station, and monitor must all support USB 3.0 and DisplayPort 1.2 to benefit from the advanced speeds
or features that these technologies provide. If one of the devices does not support these technologies, you will still have USB 2.0 and
DisplayPort 1.1 functionality.
HP UltraSlim Docking Station – Front side
1.
Docking posts
4.
Connect button
2.
Locking mechanism (lock not included)
5.
Connect light
3.
HP Dock Station Cable Lock slot (Lock not included)
QuickSpecs
HP Ultra-light Docking Stations
Overview
DA - 13639 North America — Version 11 — April 28, 2014
Page 3
